SIMPLIFIED RM44C

4x4 HDMI 2.0b (18Gbps) Fast Switch/Scaling Matrix Switch.

The RM44C HDMI Matrix switch is a fast switch 4x4 Matrix that features four HDMI inputs and four HDMI outputs  It provides true matrix routing for HDMI signals.  It supports transmission of video (resolutions up to 2160p@60Hz Ultra HD (4:4:4) and supports high resolution audio formats such as LPCM7.1, Dolby TrueHD, Dolby Digital Plus, Atmos, and DTS-HD Master Audio.  The RM44C will also pass HDR High Dynamic Range information as well (8, 10, 10+, Dolby Vision).  Each output has scaling options for easier integration of unlike displays.  In addition, there is a CEC control feature allowing the matrix to turn on the displays.  Features are adjustable in the Web GUI with both Admin and User login settings.

• HDMI2.0b (18Gbps), HDCP2.2/HDCP1.4 compliant.

• Supports video formats up to 4k2k@60Hz with 24bit RGB/YCbCr 4:4:4YCbCr4:2:2, and up to 4k2k@60Hz with 12bit YCbCr 4:2:0.

• Built in Web GUI with Admin and User options.

• Each output has scaling.

• Each Output has an audio breakout.

• Built in signal pattern generator.

• Built in CEC editor to allow control of connected devices.

• Supports RGB, YCbCr 4:4:4, YCbCr 4:2:2 and xvYCC video formats.

• Supports HDR8/10/10+ and Dolby Vision.

• Supports high resolution VESA mode video formats up to QSXGA@60Hz.

• Audio formats supported: PCM up to 192kHz, compressed audio (IEC 61937), DSD, DST, DTS, Dolby TrueHD, Atmos, 7.1, and 5.1 formats.

• Sophisticated EDID management with scaling allows different resolution displays to integrate easily.

• Control of the via IR Remote Control or on-panel control.

• 3 Year Warranty.
